FrontMowerDeck
•2caster-fork-shaftbushings(Figure52)
•5spindle-shaftbearings(locatedonthespindlehousing)
asshowninFigure52
•3idler-arm-pivotbushings(locatedontheidler-pivot
shaft)asshowninFigure52
Figure52
FrontLiftAssemblies
•2lift-armbushings(Figure53)
•2lift-armballjoints(Figure53)
•2frontdeck-lift-cylinderpivots(Figure53)
Figure53
SideMowerDecks(EachSide)
•4caster-fork-shaftbushings(Figure54)
•3spindle-shaftbearings(locatedonthespindlehousing)
asshowninFigure54
•2idler-arm-pivotbushings(locatedontheidler-pivot
shaft)asshowninFigure54
Figure54
SideLiftAssemblies(PerSide)
•3mainlift-armbushings(Figure55)
•1lift-cylinderbushing(Figure55)
Figure55
