Figure82
1.Hydraulicmotor2.Mountingbolts
6.Liftthemotoroffthemowerdeckandlayitontop
ofthemowerdeck.
7.Removetheoldbeltfromaroundthespindlepulleys
andidlerpulley.
8.Routethenewbeltaroundthespindlepulleysand
idler-pulleyassembly(Figure83).
114-0922
Figure83
9.Adjustthestopscrewontheidlerpulleyandtighten
thejamnuts.
ReplacingtheSideMower-DeckBelts
Note:Toremovethelowerbelt,youmustremovetheupper
beltrst.
1.Lowerthemowerdecktotheoor.
2.Removethebeltcoversfromthetopofthemower
deckandsetthecoversaside.
3.Removetheboltssecuringthehydraulicmotortothe
mowerdeck(Figure82).
4.Liftthemotoroffthemowerdeckandlayitontop
ofthemowerdeck.
5.Usingaratchetwrenchorsimilartool,movetheidler
pulleysawayfromthedrivebelttoreleasethebelt
tensionandallowthebelttoslipoffthepulleys(Figure
84).
Figure84
1.Idlerpulleys
6.Removetheoldbeltfromaroundthespindlepulleys
andidlerpulley.
7.Routethenewbeltaroundthespindlepulleysand
idler-pulleyassembly(Figure85andFigure86).
Figure85
Rightdeck
Figure86
Leftdeck
