Toro EVOLUTION Series Quick Start Guide

12
Step 4 – Connectvalveswirestothecontroller-Securethevalvecommonwire(white)toeitherofthetwoterminalslabeledCOM.Securetheindividual
valve wires to the appropriate zones they control, Zone 1 valve to terminal 1, Zone 2 valve to terminal 2, etc.
   Connectmastervalve/pumprelaywirestothecontroller-Securethevalvecommonwire(white)toeitherofthetwoterminalslabeledCOM.
Secure the Master Valve or Pump Relay wire to the terminal labeled MV/PUMP.
Caution: To prevent controller damage, do not connect the pump motor starter directly to the controller. Connect sensor wires to the
controller - Remove the jumper wire from the SENSORS terminals. Secure the two sensor wires to the sensor terminals. Refer to the provided
sensor instructions for further installation instructions.
Step 5 – Test for proper operation.
Schedule Setup
The EVOLUTION
®
controller displays only one schedule by default. See the Advanced Functions section of the full User’s Guide version to activate additional
schedules if needed.
Water Days Setup
The EVOLUTION
®
controllerallowsforexiblewateringbygivingyoufourscheduleoptions:7-day,Evendays,OdddaysorIntervaldays.Bydefault,the
7-day schedule is set for the schedule. To set watering days to Odd, Even or Interval, see the Advanced Functions section.
The7-dayscheduleallowsyoutoactivateorturnoanyofthedaysintheweek.Bydefault,alldaysareactive.
Step 1 – Press the SCHEDULES button.
Step 2 – (Forcontrollerswithmultipleactiveschedulesonly.)
Use the Up or Down arrows to select the Schedule you want to edit. Press SELECT .
Note: The Schedule and Zone names can be customized using the EVOLUTION
®
Software which can be accessed at www.toro.com/
evolution.
Step 3 – Use the Up or Down arrows to navigate to WATER DAYS. Press SELECT .
Step 4 – Use the Up or Down arrows to select WEEKDAY, ODD, EVEN or INTERVAL. Press SELECT .
Step 5 – (WEEKDAY Option)TheWEEKDAYscheduleallowsyoutoactivateorturnoanyofthedaysintheweek.Bydefault,alldaysareactive.
Use the Left or Right arrows to navigate within the days of the week. Use the Up or Down arrows to activate orturno
the day for watering. Repeat for all days of the week.
WEEKDAY
S M T W T F S
TODAY IS TUESDAY

Toro EVOLUTION Series Specifications

General

Weather Sensor Compatibility	Yes
Output Voltage	24 VAC
Display	LCD
Wi-Fi Connectivity	Yes (with optional Wi-Fi module)
Mounting	Indoor/Outdoor
Maximum Load Current	0.5 amps per station
Operating Temperature	-40°C to 60°C
Enclosure Rating	NEMA 3R
Weight	Varies by model
Zones	4 to 16 (in modules of 4)
