Toro EVOLUTION Series Quick Start Guide

23
Specications
PowerSpecications:
CabinetDimensions:
•11.25”Wx7.75”Hx4.5”D(286x197x114mm)
Surge Protection
• 1.5 KV common mode; 1.0 KV normal mode
BatteryType:
•9VAlkaline(notincluded)
• US and Canada
 InternalTransformer,Class2,ULListed,CSACertied(orequivalent)
Input:120VAC,60Hz
Output:24VAC,60Hz,1.25A
• Outside US and Canada
Internal Transformer, Meets TUV, VDE and SAA Requirements
Input:220–240VAC,50/60Hz
Output:24VAC,50/60Hz,30VA
•TotalMaximumLoad:
1.0A @ 24 VAC
EPA Water Sense Qualication Criteria
EVOLUTION
®
controller settings and accessories for EPA WaterSense
®
programqualicationtest:
Program 1 Program 2 Program 3
 Zone#1=6Min Zone#3=9Min Zone#5=21Min
 Zone#2=6Min Zone#4=6Min Zone#6=17Min
 StartTimes=1:00am,2:00am StartTime=3:00am StartTimes=4:00am,6:00am,8:00am
 SkipDays=0(WaterEveryday) SkipDays=0(WaterEveryday) SkipDays=0(WaterEveryday)
Accessories:
• Smart Connect
TM
(ModelNo.EVO-SC)
• Smart Connect
TM
WeatherSensor(ModelNo.EVO-WS)
Toro Contact Information
For U.S.A. support, call 1-877-345-8676.
For global support, send email to evolution@toro.com.
Visit the EVOLUTION
®
website for the latest news and information at www.toro.com/evolution.

Toro EVOLUTION Series Specifications

General

Weather Sensor Compatibility	Yes
Output Voltage	24 VAC
Display	LCD
Wi-Fi Connectivity	Yes (with optional Wi-Fi module)
Mounting	Indoor/Outdoor
Maximum Load Current	0.5 amps per station
Operating Temperature	-40°C to 60°C
Enclosure Rating	NEMA 3R
Weight	Varies by model
Zones	4 to 16 (in modules of 4)
