7
NEXT START 06:00AM
The scroll down arrow
indicates that additional information are available. Use the Down arrow to reveal the
additionalmessage(s).
FREEZE HOLD
Indicates that the measured temperature from the rain/freeze sensor or weather station is the same of less than the set
value in the FREEZE OFF menu parameter.
ET HOLD
Indicates that all scheduled watering are placed on hold due to weather condition measured by the weather station.
Scheduled watering will resume once the weather condition returns to conditions that permits watering.
C
Message Bar
ALERT: PRESS HELP
Indicates that the controller detected a condition that needs user attention. Check the alert messages in the Alerts
menu under the Help/Setup function. For a list of the Alert messages and description, please refer to the Alert
Messages section on page 22.
WATER OFF 04 DAYS
Indicatesthatscheduledwateringhasbeensuspendedfortheindicateddays.Wateringcanbeturnedofrom1–14
days,RemainsOorwilloperateatthenextscheduledstart.
SYSTEM OK
Indicates that the system is functioning as expected.
Setup Screen
Uponpowerup,theinitializationscreenwilldisplaybriey.Oninitialpowerup,theEVOLUTION
®
will display the SETUP screen.
This SETUP screen is only accessed during initial power up or after a factory reset is performed.
WELCOME
INITIALIZING
PLEASE WAIT . . .
SETUP
LANGUAGE ENGLISH
DATE FORMAT MM/DD/YY
CLOCK 12 HOUR
TIME 12:01AM
DATE 01/01/13
BEGIN WEEK SUNDAY
Set Language
Select the preferred display language. Select from English, Spanish, French, German, Italian or Portuguese.
Step 1 – While LANGUAGE is selected, press the Right arrow or SELECT .
Step 2 – Use the Up or Down arrowstoselectfromEnglish(default),Spanish,French,German,ItalianorPortuguese.
Press SELECT .
Step 3 – Navigate to the next item or press the HOME button to return to the main screen if setup is complete.
