Toro EVOLUTION Series Quick Start Guide

6
Home Screen Messages
HOME
01:09PM
WED
01/08
NEXT START 06:00AM
ALERT: PRESS HELP
A
B
C
A
Title Bar
HOME
Thebatteryiconindicatesthatthecontroller’sVACpowerisoandthetimerisrunningunderbatterypower.
Note: The9-voltbatteryisusedtoallowprogrammingwhentheVACpowersupplyiso,butitwillnotactivate
any zones.
B
Main Display
01:09PM
TUES
01/08
Displays the current time, day of the week and date.
SCHEDULE A/B/C OR AUX
Indicateswhichschedule(A,BorC)orauxiliaryisassociatedwiththedisplayedstatus.IfonlyScheduleAisactive,
EVOLUTION
®
will not display the Schedule “A”, “B” and “C” or AUX.
SCHEDULE A GROW IN
Indicates the displayed schedule is set as Grow In. The Grow In option is set in the Schedule Details under the
Advanced menu.
NOT WATERING TODAY
Indicates that the displayed schedule will not water that day.
NOT ACTIVE TODAY
Thedisplayedauxiliaryschedule(Aux)willnotactivatethatday.
ZONE 1 00:05
Indicates that Zone 1 is active with a 5-minute remaining runtime. Pressing the Right arrow will deactivate the
runningzoneandactivatethenextzone(ifadditionalzonesarescheduled)inthescheduleregardlessoftheremaining
runtime.
WATERING COMPLETE
The displayed schedule completed its watering cycle.
SCHEDULE COMPLETE
Thedisplayedauxiliaryschedule(Aux)completeditscycle.
NEXT START 06:00AM
Indicatesthenextstarttimeofthedisplayedwateringorauxiliary(Aux)schedule.
DELAY 00:05
Indicates that the controller is performing a zone delay before the next zone in the schedule is activated. The zone
delay is set in the Schedule Details under the Advanced menu.
SOAK 00:05
Indicates that the active zone is performing a soak delay before continuing operation. The soak delay is set in the Zone
Details under the Advanced menu.
RAIN DELAY
Indicates that the rain sensor is activated and the schedule is delayed until the rain sensor dries up.
RAIN DELAY 02 DAYS
If Dryout Days is set, the controller will indicate Rain Delay until the number of Dryout Days are completed. Pressing
the Right arrowwilldeactivatetheDryoutDaysandtheSchedule(s)willcontinuenormaloperation.

Toro EVOLUTION Series Specifications

General

Weather Sensor Compatibility	Yes
Output Voltage	24 VAC
Display	LCD
Wi-Fi Connectivity	Yes (with optional Wi-Fi module)
Mounting	Indoor/Outdoor
Maximum Load Current	0.5 amps per station
Operating Temperature	-40°C to 60°C
Enclosure Rating	NEMA 3R
Weight	Varies by model
Zones	4 to 16 (in modules of 4)
