Toro groundmaster 7210 - InfoCenter Information Display

buttonwillbelabeledwithanicondisplayingits
currentfunction.
InfoCenterIconDescription
SERVICEDUE
Indicateswhenscheduledservice
shouldbeperformed
RPM
Enginerpm/status—indicatesthe
enginerpm
Hourmeter
Infoicon
Stationaryregenerationrequired
Glowplugsareactive
Operatormustsitinseat
ParkingBrakeIndicator—indicates
whentheparkingbrakeisOn
CoolantTemperature-indicatesthe
enginecoolanttemperatureineither
°Cor°F
Temperature(hot)
Deniedornotallowed
EngineStart
Stoporshutdown
Engine
Keyswitch
PINcode
HydraulicOilT emperature-indicates
thehydraulicoiltemperature
CANbus
InfoCenter
Badorfailed
Bulb
OutputofTECcontrollerorcontrol
wireinharness
High:overallowedrange
InfoCenterIconDescription(cont'd.)
Low:underallowedrange
/
Outofrange
Switch
Operatormustreleaseswitch
Operatorshouldchangetoindicated
state
Symbolsareoften
combinedtoform
sentences.Some
examplesareshown
below
Enginestartdenied
Engineshutdown
Enginecoolanttoohot
Sitdownorsetparkingbrake
UsingtheMenus
ToaccesstheInfoCentermenusystem,pressthe
menuaccessbuttonwhileatthemainscreen.This
bringsyoutothemainmenu.Refertothefollowing
tablesforasynopsisoftheoptionsavailablefrom
themenus:
MainMenu
MenuItemDescription
FaultsTheFaultsmenucontains
alistoftherecentmachine
faults.RefertotheService
ManualoryourAuthorized
ToroDistributorformore
informationontheFaults
menuandtheinformation
containedthere.
ServiceTheServicemenucontains
informationonthemachine
suchashoursofuseandother
similarnumbers.
17
