AcceleratorPedal
Theacceleratorpedal(Figure8)givesyoutheability
tovarythegroundspeedofthesprayer.Pressingthe
pedalincreasesgroundspeed.Releasingthepedal
slowsthesprayerandreducestheenginespeedto
idle.
g023035
Figure8
1.Clutchpedal
3.Acceleratorpedal
2.Brakepedal
ClutchPedal
Fullypresstheclutchpedal(Figure8)todisengage
theclutchwhenstartingtheengineorshifting
transmissiongears.Releasethepedalsmoothlywhen
thetransmissionisingeartopreventunnecessary
wearonthetransmissionandotherrelatedparts.
Important:Donotridetheclutchpedalduring
operation.Theclutchpedalmustbefullyoutor
theclutchwillslip,causingheatandwear.Never
holdthemachinestoppedonahillusingthe
clutchpedal.Damagetotheclutchmayoccur.
BrakePedal
Usethebrakepedaltostoporslowthesprayer
(Figure8).
CAUTION
Brakescanbecomewornorcanbeadjusted
incorrectlyresultinginpersonalinjury.
Ifbrakepedaltravelstowithin2.5cm(1inch)
ofthesprayeroorboard,adjustorrepairthe
brakes.
ParkingBrake
Theparkingbrakeisalargelevertotheleftofthe
seat(Figure9).Engagetheparkingbrakewhenever
youleavetheseattopreventaccidentalmovementof
thesprayer.T oengagetheparkingbrake,pullupand
backonthelever.T odisengage,pushitforwardand
down.Ifthesprayerisparkedonasteepgrade,apply
theparkingbrakeandplaceblocksatthedownhill
sideofthewheels.
g023036
Figure9
1.Parking-brakelever
HillAssist
Hillassistpreventsthesprayerfromrollingorjerking
bytemporarilyholdingthesprayeronhillyterrain
whenyoumoveyourfootfromthebrakepedaltothe
acceleratorpedal.T oengagehillassist,engagethe
clutchandpushdownonthebrakepedalrmly.When
hillassistisengaged,thehillassisticonappears
ontheInfoCenter;refertotheMultiPro1750Turf
SprayerSoftwareGuide.Hillassistholdsthemachine
for2secondsafterreleasingthebrakepedal.
Note:Thehillassistonlytemporarilyholdsthe
machine:youcannotuseitinplaceoftheparking
brake.
DifferentialLock
Thedifferentiallockallowsyoutolocktherearaxlefor
increasedtraction.Youmayengagethedifferential
lock(Figure7)whilethesprayerisinmotion.Move
theleverforwardandtotherighttoengagethelock.
Note:Youmayneedtodrivethemachineforward
whileturningslightlytoengageordisengagethe
differentiallock.
17
