Figure14
Meshsize—applicationrate
1.Higherapplicationrate
3.Screenmeshsize
2.Lowerapplicationrate
SelectingaPressureFilter
Availablescreensizesinclude:
StandardEquipment:50meshsuctionlter(blue)
Usethepressureltertabletoidentifythescreen
meshforthespraynozzlesyouareusingbased
onchemicalsproductsorsolutionswithaviscosity
equivalenttowater.
PressureFilterTable
SprayNozzle
ColorCode(ow
rate)
ScreenMesh
Size*
FilterColorCode
Asrequiredforlow
viscositychemicals
orsolutionsorlow
applicationrates
100
Green
Yellow(0.2gpm)
80Yellow
Red(0.4gpm)
50Blue
Brown(0.5gpm)
50Blue
Gray(0.6gpm)
50Blue
White(0.8gpm)
50Blue
Blue(1.0gpm)
50Blue
Green(1.5gpm)
50Blue
Asrequiredforhigh
viscositychemicals
orsolutionsorhigh
applicationrates
30Red
PressureFilterTable(cont'd.)
SprayNozzle
ColorCode(ow
rate)
ScreenMesh
Size*
FilterColorCode
Asrequiredforhigh
viscositychemicals
orsolutionsorhigh
applicationrates
16Brown
*Themeshsizeofthepressureltersinthistable
arebasedonspraychemicalsorsolutionswiththe
viscosityequivalenttowater.
Important:Whenyouspraywithhigherviscosity
(thicker)chemicalproductsorsolutionswith
wettablepowders,youmayneedtouseacoarser
screenmeshfortheoptionalpressure-lter;refer
toFigure15.
g214211
Figure15
Meshsize—chemicalorsolutionviscosity
1.Higher-viscositychemicals
orsolutions
3.Screenmeshsize
2.Lower-viscositychemicals
orsolutions
Whenyousprayatahigherapplicationrate,consider
usingancourseroptionalpressure-ltermesh;refer
toFigure16.
24
