ControlHandleInstallation(continued)
g311248
Figure85
4.ReapplyLoctite.Installtheboltsecuringthereferencebartothemotion
controlarm.Torqueboltto6N•m(53±7in-lb).
5.Installtheboltandnutsecuringthemotioncontrolarmtothecontrolrod.
Torqueboltandnutto6N•m(53±7in-lb).
g311247
Figure86
6.Installtheboltandnutsecuringthedampertothecontroltower.Torque
boltandnutto5N•m(48±5in-lb).
