- 8 -
When using this product for the B-EP2DL-G or B-EP4DL-G, set the printer mode to TPCL-LE,
TPCL-LE1, TPCL, or TPCL1 by using the Printer Setting Tool or the keys on the printer. For the key
operations, refer to the B-EP Series Key Operation Specification.
When a device font is used, the actual print result looks different from the print preview. Print the label
format, and check and adjust the label format.
RFID fonts are not supported.
The stock sizes, A4, A5, and A6, shown in this product do not define the paper size in DEVMODE
(DMPAPER_A4, DMPAPER_A5, and DMPAPER_A6). They are the stock IDs unique to this product.
The following table shows the stock IDs for the standard stock types registered to the printer driver.
When a new stock type is additionally registered, an ID will be assigned in the order of registration,
starting from 257. The stock ID can be changed on the Edit Stock screen. Use these IDs when
specifying or checking a stock size of dmPaperSize.
Stock name
Stock ID
Current
Old
USER
256
256
2x4
32000
257
4x4
32001
258
4x6
32002
259
200x85
32004
260
A4
32005
261
A5
32006
262
A6
32007
263
JAMA L
32010
267
JAMA M
32011
268
JAMA S
32012
269
Form-F
32009
270
Form-A
32008
271
185x85
32003
272
6x4
32013
---
2x2
32014
---
3x3
32015
---
In the case an export file of the previous version is imported, the preset paper settings may be reset.
After importing the preset settings, check the settings.
When Access2007 is used, some paper names may not be correctly shown. To set the paper names,
click the [Page Setup] and open the Edit Stock dialog.
When the LPT or COM port configuration is changed under Windows Vista/Server2008, conduct it with
administrative privilege.
When the port configuration is changed under
Windows Vista/Server2008, the dialog box on the
right may be displayed. In this case, change the
port configuration with administrative privilege.
ATTENTION:
The IDs for the standard stock types have been totally changed from Version
7.2 M-2, which causes mismatching in the IDs between the older printer
driver and the new printer driver. Therefore, when printing is performed
from the application which manages the stock types for Excel, Access, etc.
by their IDs assigned by the older printer driver version, a wrong stock may
be selected.
In this case, change the stock IDs back to the former ones using the
following procedure.
(1) For the user-added stocks, import the settings of the previous printer
driver to the new printer driver. (User-added stocks are imported with
their original IDs.)
(2) For the standard stock types, the stock IDs registered to the new printer
driver are unchangeable. So, select the standard stock type, click on the
[New], and save it as a new stock assigning the former ID listed the table
on the left.
The stock list is sorted by ascending order of stock name (Symbol, number,
alphabet, Kana, and Kanji), regardless of the stock ID.
