2
© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
SELF-DIAGNOSTIC MODE
2 - 71
364 Scanner Data transfer of
characteristic value of
scanner / SLG board
SYS board
SCN - SYS Transfers the
characteristic values of
the scanner (shading
correction factor / RGB
color correction /
reproduction ratio color
aberration correction /
shading position
correction factor /
reproduction ratio
correction value in
primary scanning
direction) from the
SRAM of the SLG
board to the SRAM of
the SYS board.
6
365 RADF RADF leading
edge position
1 adjustment
for single
sided
original
ALL 50
<0-100>
SYS When the value
increases by “1”, the
copied image of original
fed from the RADF
shifts toward the trailing
edge of paper by
approx. 0.2 mm.
1
366 for double
sided
original
ALL 50
<0-100>
SYS 1
Adjustment mode (05)
Code
Classific
ation
Items
Functi
on
Default
<Accept
able
value>
RAM Contents
Proce
dure
