e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
ADJUSTMENT
3 - 40
3.2.12 Maximum toner density adjustment to paper type
The maximum toner amount adhering to the paper can be controlled.
<Adjustment Mode (05)>
The larger the value is, the more frequently fusing offsetting occurs.
<Procedure>
The procedure is the same as that of  P.3-31 "3.2.2 Density adjustment".
3.2.13 Maximum text density adjustment
The maximum text density of each color at Full Color Mode can be adjusted as follows.
<Adjustment Mode (05)>
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustments according to the following procedure.
Be sure that this adjustment is made after performing  P.3-29 "3.2.1 Automatic gamma
adjustment".
<Procedure>
The procedure is the same as that of  P.3-31 "3.2.2 Density adjustment".
Code Paper type Remarks
1612 Plain paper The smaller the value is, the toner amount adhered
decreases of the high density area (ex. prevention of fusing
offsetting, etc.).
Acceptable values: 0 to 255
(Default: Plain paper: 255, Thick paper 1: 255,
Thick paper 2: 255, Thick paper 3: 255, OHP film: 240,
special paper 1: 255, special paper 2: 255,
Recycled paper: 255, Thick paper 4: 255)
1613 Thick paper 1
1614 Thick paper 2
1615 Thick paper 3
1616 OHP film
1617 Special paper 1
1618 Special paper 2
1619 Recycled paper
1620 Thick paper 4
Color Code Item to be adjusted Remarks
Yellow 1630 Maximum text density The larger the value is, the darker the maximum text density
of each color to be adjusted becomes.
Acceptable values: 0 to 10 (Default: 5)
Magenta 1631
Cyan 1632
Black 1633
To Next Page
