e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 76
2.6 SETTING MODE (08)
The items in the setting code list can be set or changed in this setting mode (08).
When the power should be turned OFF, be sure to shut down the equipment by pressing the
[ON/OFF] button for a few seconds.
1. The Service Handbook contains only the selected codes while the Service Manual contains
all codes.
2. The digit after the hyphen in “Code” of the following table is a sub code.
3. In “RAM”, the SRAM of the board in which the data of each code is stored is indicated. “M”
stands for the LGC board, “SYS”, “NIC” and “UTY” stands for the SYS board.
2.6.1 Classification List of Setting Mode (08)
Classification
Setting Mode (08)
Given in the Service
Manual
Given in the Service
Manual and Service
Handbook
User interface
[ACS] 9698
[AMS] 605
[Feeding paper media] 9185-0 to 1
[X in 1] 650
[Color specification] 643, 644
[Indicator] 671
[Edit copying] 645, 646
[Sound] 610, 969, 970
[Counter] 202
[Cascade] 652, 653
[ACS] 268
[Screen] 207, 602, 9985
[Administrator] 263, 9882
[Feeding setting] 658, 659
[Language] 220, 221, 1929, 1930, 1931,
1932, 1933, 1934, 1935
[Original counter] 302
[Original direction] 628
[Copy volume] 300
[Automatic calibration] 632
[Default setting] 276, 277, 278, 279, 280,
281, 282, 283, 284, 285,
286, 289, 331, 603, 604,
607, 618, 642, 9986
[Jam releasing] 9359
[Offsetting between jobs] 682
[Security level] 1708
[Sorting] 627, 634, 641, 649
[Timer] 204, 205, 206
[Template] 1140
[Image shift] 636, 1429, 1430, 8546
[Tray reset] 648
[Panel calibration] 9051
