Toshiba e-studio2330c Service Handbook

e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
PREVENTIVE MAINTENANCE (PM)
5 - 38
5.6.16 PFP (KD-1023)
Fig. 5-33
Items to check Cleaning
Lubric
ation/
Coatin
g
Replacement
Operati
on
check
Parts
list
<P-I>
(x 1,000 sheets)
(x 1,000 drive
counts)
P1 Pickup roller
(upper/lower)
A80-5-20
P2 Feed roller
(upper/lower)
A80-5-24
P3 Separation roller
(upper/lower)
AAV, W2 80 - 5-5
P4 Drive gear
(tooth face)
W1
P1 P2
P3
P3
P1
P2
