e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE AND TROUBLESHOOTING
6 - 52
6.2.12 Paper feeding system related service call
[C040] PFP motor abnormality
Is the PFP motor working? (Perform the output check: 03-109/159)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NO 1. Check if the signal line connector CN503 of the PFP motor is disconnected.
2. Check if the power line connector CN502 of the PFP motor is disconnected.
3. Check if the connector CN246 on the PFP board is disconnected.
4. Check if the signal line connector CN241 on the PFP board is
disconnected.
5. Check if the power line connector CN242 on the PFP board is
disconnected.
6. Check if the connector CN349 on the LGC board is disconnected.
7. Check if the connector pins are disconnected or the harnesses are open
circuited.
8. Check if the conductor patterns on the PFP motor board, PFP board and
LGC board are short circuited or open circuited.
9. Replace the PFP motor.
10.Replace the PFP board.
11.Replace the LGC board.
YES
Is the LED on the PFP motor board lit without flashing?
|
|
|
|
|
|
|
|
NO 1. Check if the connector pins are disconnected or the harnesses are open
circuited.
2. Check if the conductor patterns on the PFP motor board, PFP board and
LGC board are short circuited or open circuited.
3. Replace the PFP motor.
4. Replace the PFP board.
5. Replace the LGC board.
YES
1. Check if the PLL lock signal CN246-8 pin output from the PFP board is always “L” level.
2. Check if the voltage supplied to the microcomputer input terminal IC5-17 pin is always “L”
level.
3. Replace the PFP board.
4. Replace the LGC board.
To Next Page
