2
© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
SELF-DIAGNOSTIC MODE
2 - 95
2.6.6 System
Setting mode (08)
Code
Classific
ation
Items
Functi
on
Default
<Accept
able
value>
RAM Contents
Proce
dure
250 Maintena
nce
Service technician
telephone number
ALL 0
<32
digits>
SYS A telephone number
can be entered up to 32
digits. Use the
[MONITOR/PAUSE]
button to enter a
hyphen(-).
11
253 Maintena
nce
Error history display ALL - SYS Displays the latest 20
errors data
2
343 User
interface
Black-free function ALL 0
<0-1>
SYS 0: Disabled
1: Enabled
If this code is set to "1"
(enabled), 08-588 is
automatically set to "1"
(black) and "0" (ACS)
and "2" (Full color)
cannot be selected. If
08-629 is set to "0"
(OFF) and 08-1482 is
set to "1" (ON), this
code is set to "0"
(Disabled) and "1" (ON)
cannot be set.
1
662 General Clearing of SMS partition ALL - SYS Clears SMS partition.
(Performs when the
service call [F106] has
occurred.)
3
666 General BOX partition clearing ALL - SYS Initializes the Electronic
Filing.
3
667 General /SHA partition clearing ALL - SYS Initializes the shared
folder.
3
670 General HDD diagnostic menu
display
ALL - SYS Display the HDD
information
(Ch.7.2.2)
2
684 General Rebuilding all databases ALL - SYS Rebuilds all databases. 3
690 General HDD formatting ALL 2
<2>
SYS 2: Normal formatting 7
692 Maintena
nce
Performing panel
calibration
ALL - SYS Performs the calibration
of the pressing position
on the touch panel
(LCD screen). The
calibration is performed
by pressing 2 reference
positions after this code
is started up.
1
693 General Initialization of NIC
information
ALL - SYS Returns the value to the
factory shipping default
value.
3
694 General Performing HDD testing ALL - SYS Checks the bad sector. 3
To Next Page
