e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 4
2.1 Input check (Test mode 03)
<Operation procedure>
Initialization is performed before the equipment enters the test mode.
Fig. 2-2 Example of display during input check
Items to be checked and the condition of the equipment when the buttons [A] to [H] are highlighted are
listed in the following pages.
The status of each input signal can be checked by pressing the [FAX] button, [COPY] button and
the digital keys in the test mode (03).
[0][3]
[POWER]
[START]
[FAX]
or
[COPY]
[Digital keys]
[CLEAR]
(LCD ON)
[POWER] OFF/ON
(Exit)
To Next Page
