© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
SELF-DIAGNOSTIC MODE
2 - 5
[FAX] button: OFF/[COPY] button: OFF ([FAX] LED: OFF/[COPY] LED: OFF)
Digital
key
Button Items to check
Contents
Highlighted display
e.g.
Normal display
e.g.
[1]
A- --
B- --
C Used toner paddle motor lock detection sensor Sensor blocked Sensor not blocked
D PWA-F-SRAM connection detection Not connected Connected
E K drum phase sensor Sensor blocked Sensor not blocked
F Color drum phase sensor Sensor blocked Sensor not blocked
G- --
H Waste toner cover open/close detection switch OPEN CLOSE
[2]
A- --
B PFP upper drawer detection switch Drawer not installed Drawer present
C PFP upper drawer paper stock sensor Paper almost empty Paper present
D PFP upper drawer feed sensor Paper present No paper
E PFP connection Not connected Connected
F PFP side cover open/close switch Cover opened Cover closed
G PFP upper drawer empty sensor No paper Paper present
H PFP upper drawer tray-up sensor Tray at upper limit
position
Other than upper
limit position
[3]
A- --
B- --
C IMG board connection Not connected Connected
D- --
E- --
F IPC board connection Not connected Connected
G- --
H HSYNC error Error Normal
[4]
A 2nd drawer tray-up sensor Tray at upper limit
position
Other than upper
limit position
B 1st drawer tray-up sensor Tray at upper limit
position
Other than upper
limit position
C 2nd drawer paper stock sensor Paper almost empty Paper present
D 1st drawer paper stock sensor Paper almost empty Paper present
E 2nd drawer detection switch Drawer not installed Drawer present
F 1st drawer detection switch Drawer not installed Drawer present
G 2nd drawer empty sensor No paper Paper present
H 1st drawer empty sensor No paper Paper present
[5]
A High voltage control leak detection status Normal Abnormal
B Fuser unit thermistor connection detection Connected Not connected
C Fuser unit new BAM judging signal-1 Old New BAM
D Bridge unit transport sensor-2 (Exit sensor) Paper present No paper
E Bridge unit cover open/close detection switch Cover opened Cover closed
F Bridge unit transport sensor-1 (Entrance
sensor)
Paper present No paper
G Bridge unit paper full detection sensor Paper full Paper not full
H Bridge unit connection Not connected Connected
