Toshiba e-studio2330c Service Handbook

e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 6
[6]
A- --
B- --
C- --
D- --
E- --
F- --
G- --
H- --
[7]
A K process unit connection signal Not connected Connected
B C process unit connection signal Not connected Connected
C M process unit connection signal Not connected Connected
D Y process unit connection signal Not connected Connected
E Paper clinging detection sensor No paper Paper present
F Registration sensor Paper present No paper
G Image position aligning sensor (rear) Toner pattern
detection
H Image position aligning sensor (front) Toner pattern
detection
[8]
A- --
B PFP lower drawer detection switch Drawer not installed Drawer present
C PFP lower drawer paper stock sensor Paper almost empty Paper present
D PFP lower drawer feed sensor Paper present No paper
E PFP motor rotation status (Motor is rotating at
output mode (03))
Abnormal rotation Normal rotation
F- --
G PFP lower drawer empty sensor No paper Paper present
H PFP lower drawer tray-up sensor Tray at upper limit
position
Other than upper
limit position
[9]
A LCF tray bottom sensor Tray at bottom
position
Other than upper
limit position
B LCF standby side paper misload detection
sensor
Properly loaded Paper misload
C LCF drawer detection switch Drawer not installed Drawer present
D- --
E- --
F- --
G- --
H Paper stock sensor at LCF feed side Paper almost empty Paper present
[0]
A LCF end fence home position sensor Fence home
position
Other than home
position
B LCF end fence stop position sensor Fence stop position Other than stop
position
C Empty sensor at LCF standby side No paper Paper present
D LCF side cover open/close switch Cover closed Cover opened
E LCF motor rotation status (Motor is rotating at
output mode (03))
Normal rotation Abnormal rotation
F LCF tray-up sensor Tray at upper limit
position
Other than upper
limit position
G LCF feed sensor No paper Paper present
H Empty sensor at LCF feed side Paper present No paper
Digital
key
Button Items to check
Contents
Highlighted display
e.g.
Normal display
e.g.
