PREVENTIVE MAINTENANCE (PM)
5 - 42
5.9 Maintenance Part List
The parts used for the maintenance of this equipment are as follows.
No. Item Purpose
Parts list
<P-I>*
1 Cleaning brush Cleaning inside of the equipment 101-2
2 Doctor blade cleaning jig Cleaning the doctor blade 101-3
3 Wire holder jig Fixing the wire at the assembly of the carriage wire 101-4
4 Developer material nozzle Pouring the developer material (attached to the
developer bottle)
101-5
5 Doctor-sleeve gap jig Measuring the gap between the developer sleeve and
the doctor blade (gauge 0.60, 0.65, 0.70)
101-6
6 Belt tension jig Adjusting the belt tension at the installation of the
scan motor
101-7
7 Separation plate gap jig Measuring the gap between the separation plate and
the fuser belt
101-8
8 Drum bag Storing the drum 101-10
9 Download jig (DLM board) Updating the scanner/options ROM 102-1
10 ROM Installing the DLM board 102-10
11 Download jig-2 (6 Flash ROMs) Updating the system/engine/scanner ROM 102-2
12 ROM writer adapter (For 1881) Writing the data of PWA-DWNLD-350-JIG2 102-4
13 ROM writer adapter (For 1931) Writing the data of PWA-DWNLD-350-JIG2 102-5
14 Harness jig Updating the converter PC board 21-3
15 Doctor-sleeve gap jig Measuring the gap between the developer sleeve and
the doctor blade (gauge 0.75)
101-27
*:
Part list <P-I> represent
s the page item
in “e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C Service Parts List”.
No.1-13,15: Refer to “e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C Service
Parts List”
No.14 : Refer to “MJ-1101 Service Parts List”
