ADJUSTMENT
3 - 13
[B] Adjustment by direct code entry
The aligning amount is adjusted by using the following codes in Adjustment Mode (05).
*Weight:
Plain paper: 64 to 105 g/m
2
(17 lb. Bond to 28 lb. Bond)
Thick paper 1: 106 to 163 g/m
2
(28 lb. Bond to 60 lb. Cover (90 lb. Index))
Thick paper 2: 164 to 209 g/m
2
(61 lb. Cover to 77.3 lb. Cover (115.7 lb. Index))
Thick paper 3: 210 to 256 g/m
2
(77.3 lb. Cover to 94.5 lb. Cover (141.4 lb. Index))
Thick paper 4: 257 to 280 g/m
2
(94.5 lb. Cover to 100 lb. Cover (150 lb. Index))
Drawer Code Sub code
Paper size
(Select the paper size with
the sub code.)
Paper type
*
1st drawer
(CST1)
4100 0,1,2,3,4 0: 330 mm or longer
(13.0 inches or longer)
1: 220–329 mm
(8.7–12.9 inches)
2: 205–219 mm
(8.1–8.6 inches)
3: 160-204 mm
(6.3–8.0 inches)
4: 159 mm or shorter
(6.26 inches or shorter)
Plain paper
4115 0,1,2,3,4 Thick paper 1/Thick paper 2/
Thick paper 3
4122 0,1,2,3,4 Plain paper
(e-STUDIO3530C/4520C, black
only)
2nd drawer
(CST2)
4101 0,1,2,3,4 Plain paper
4116 0,1,2,3,4 Thick paper 1/Thick paper 2/
Thick paper 3
4123 0,1,2,3,4 Plain paper
(e-STUDIO3530C/4520C, black
only)
3rd drawer
(CST3)
4108 0,1,2,3,4 Plain paper
4117 0,1,2,3,4 Thick paper 1/Thick paper 2/
Thick paper 3
4124 0,1,2,3,4 Plain paper
(e-STUDIO3530C/4520C, black
only)
4th drawer
(CST4)
4109 0,1,2,3,4 Plain paper
4118 0,1,2,3,4 Thick paper 1/Thick paper 2/
Thick paper 3
4125 0,1,2,3,4 Plain paper
(e-STUDIO3530C/4520C, black
only)
Bypass feed 4103 0,1,2,3,4 Plain paper
4104 0,1,2,3,4 Thick paper 1
4105 0,1,2,3,4 Thick paper 2
4106 0,1,2,3,4 Thick paper 3/Thick paper 4
4107 0,1,2,3,4 OHP
4127 0,1,2,3,4 Plain paper
(e-STUDIO3530C/4520C, black
only)
4128 0,1,2,3,4 Special paper 1
4129 0,1,2,3,4 Special paper 2
LCF 4111 - Plain paper
4126 - Plain paper (e-STUDIO3530C/
4520C, black only)
ADU 4110 0,1,2,3,4 0: 330 mm or longer
(13.0 inches or longer)
1: 220–329 mm
(8.7–12.9 inches)
2: 205–219 mm
(8.1–8.6 inches)
3: 160-204 mm
(6.3–8.0 inches)
4: 159 mm or shorter
(6.26 inches or shorter)
Plain paper
4120 0,1,2,3,4 Thick paper 1
