e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
REPLACEMENT OF PC BOARDS/HDD
7 - 14
Note:
The shape of the SRAM board for the SYS
board differs from the one for the LGC board.
Be sure to assemble the correct SRAM
board.
Fig. 7-35
SRAM board
(for SYS board)
SRAM board
(for LGC board)
