SELF-DIAGNOSTIC MODE
2 - 14
280 PFP lower drawer tray-up motor ON (tray up) 2
281 RADF feed motor ON/OFF (normal rotation) 3
282 RADF feed motor ON/OFF (reverse rotation) 3
283 RADF read motor ON/OFF 3
284 RADF exit/reverse motor ON/OFF (normal rotation) 3
285 RADF exit/reverse motor ON/OFF (reverse rotation) 3
294 Reverse/exit solenoid ON/OFF 3
295 Power OFF mode 4
297 RADF fan motor ON/OFF 3
410 Toner motor (K) ON/OFF (Operational without toner cartridge K) 3
411 Toner motor (C) ON/OFF (Operational without toner cartridge C) 3
412 Toner motor (M) ON/OFF (Operational without toner cartridge M) 3
413 Toner motor (Y) ON/OFF (Operational without toner cartridge Y) 3
414 Used toner motor ON/OFF 3
415 Waste toner transport motor ON/OFF 3
417 Laser shutter (open/close) 2
433 Drum (K) recovery blade bias ON/OFF 3
434 Drum (Y/M/C) recovery blade bias ON/OFF 3
439 EPU cooling fan (low speed) ON/OFF 3
440 EPU cooling fan (high speed) ON/OFF 3
441 Fuser/exit section cooling fan (low speed) ON/OFF 3
442 Fuser/exit section cooling fan (high speed) ON/OFF 3
443 Ozone exhaust fan (low speed) ON/OFF 3
444 Ozone exhaust fan (high speed) ON/OFF 3
445 Laser unit cooling fan (low speed) ON/OFF 3
446 Laser unit cooling fan (high speed) ON/OFF 3
448 Switching regulator cooling fan ON/OFF 3
449 Internal cooling fan (low speed) ON/OFF 3
450 Internal cooling fan (high speed) ON/OFF 3
Code Function Procedure
