e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
FIRMWARE UPDATING
8 - 40
(5) Remove the cover plate.
Fig. 8-33
(6) Take off the converter PC board from the logic PC board (LGC board).
Fig. 8-34
(7) Connect the 10-pin side of the harness jig for board connection to the connector (CN2) of the
converter PC board.
Fig. 8-35
Cover plate
CN2
