Toshiba e-studio2330c Service Handbook

e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 36
78 Printer gamma correction table creation pattern
(Thick paper 2)
Refer to 3.3.1Automatic gamma adjustment
79 Printer gamma correction table confirmation
pattern
(Thick paper 2)
Refer to 3.3.1Automatic gamma adjustment
80 Printer gamma correction table creation pattern
(Thick paper 3)
Refer to 3.3.1Automatic gamma adjustment
81 Printer gamma correction table confirmation
pattern
(Thick paper 3)
Refer to 3.3.1Automatic gamma adjustment
82 Printer gamma correction table creation pattern
(Thick paper 4)
Refer to 3.3.1Automatic gamma adjustment
83 Printer gamma correction table confirmation
pattern
(Thick paper 4)
Refer to 3.3.1Automatic gamma adjustment
84 Printer gamma correction table creation pattern
(Special paper 1)
Refer to 3.3.1Automatic gamma adjustment
85 Printer gamma correction table confirmation
pattern
(Special paper 1)
Refer to 3.3.1Automatic gamma adjustment
86 Printer gamma correction table creation pattern
(Special paper 2)
Refer to 3.3.1Automatic gamma adjustment
87 Printer gamma correction table confirmation
pattern
(Special paper 2)
Refer to 3.3.1Automatic gamma adjustment
98 Grid pattern -2 (For printing K(4) / Plain paper) Refer to 3.1.8Image dimensional adjustment at the
printing section
99 Grid pattern -2 (For printing K(4) / Thick paper
1)
100 Grid pattern - 1 (Full color / Thick paper 1)
101 Grid pattern - 1 (Black / Thick paper 1)
104 Color deviation confirmation pattern (A3/LD)
111 Field curvature deviation confirmation pattern For secondary scanning position fine adjustment
200 Copier gamma adjustment pattern
(Color & black integrated / Plain paper)
Refer to 3.2.1Automatic gamma adjustment
201 Copier gamma confirmation pattern
(Color / Plain paper)
Refer to 3.2.1Automatic gamma adjustment
204 Copier gamma adjustment pattern
(Color & black integrated / Recycled paper)
Refer to 3.2.1Automatic gamma adjustment
205 Copier gamma confirmation pattern
(Color / Recycled paper)
Refer to 3.2.1Automatic gamma adjustment
206 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 1)
Refer to 3.2.1Automatic gamma adjustment
207 Copier gamma confirmation pattern
(Color / Thick paper 1)
Refer to 3.2.1Automatic gamma adjustment
208 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 2)
Refer to 3.2.1Automatic gamma adjustment
209 Copier gamma confirmation pattern
(Color / Thick paper 2)
Refer to 3.2.1Automatic gamma adjustment
210 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 3)
Refer to 3.2.1Automatic gamma adjustment
211 Copier gamma confirmation pattern
(Color / Thick paper 3)
Refer to 3.2.1Automatic gamma adjustment
212 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 4)
Refer to 3.2.1Automatic gamma adjustment
Code Types of test pattern Remarks
