Toshiba Qosmio F60 Series Maintenance Manual

1 Hardware Overview
1-4 Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL]
Figures
Figure 1-1 Front of the computer........................................................................................... 10
Figure 1-2 System unit configurations................................................................................... 11
Figure 1-3 System unit block diagram................................................................................... 12
Figure 1-4 3.5-inch FDD (USB External).............................................................................. 17
Figure 1-5 2.5-inch HDD....................................................................................................... 18
Figure 1-6 DVD Super Multi drive........................................................................................ 20
Figure 1- 7 Keyboard............................................................................................................. 24
Figure 1- 8 LCD module........................................................................................................ 25
Tables
Table 1-1 3.5-inch FDD specifications.................................................................................. 17
Table 1-2 2.5-inch HDD specifications(FUJITSU)............................................................... 18
Table 1-3 2.5-inch HDD specifications(TOSHIBA) ............................................................. 19
Table 1-4 DVD Super Multi drive outline dimensions.......................................................... 21
Table 1-5 BD-R/RE drive outline dimensions....................................................................... 22
Table 1-6 LCD module specifications................................................................................... 26
Table 1-7 Power supply output rating.................................................................................... 28
Table 1-8 Battery specifications ............................................................................................ 29
Table 1-9 Time required for charges ..................................................................................... 30
Table 1-10 Data preservation time......................................................................................... 31
Table 1-11 RTC battery charging/data preservation time ..................................................... 31
Table 1-12 AC adapter specifications.................................................................................... 32

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
