Toshiba Qosmio F60 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-16 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)
C.20 IS2100 MEDIA BRIDGE interface connector (45-pin)
Table C- 20 MEDIA BRIDGE interface connector (45-pin)
Pin No. Signal Name Pin No. Signal Name
1
FMC11-P3P
2
FMC10-P3P
3
FMC09-P3P
4
FMC08-P3P
5
FMC07-P3P
6
GND
7
FMC-P3V
8
GND
9
FMC-P3V
10
FMC14-P3P
11
FMC10-P3P
12
FMCD1-P3N
13
FMC08-P3P
14
FMC05-P3P
15
FMC02-P3P
16
FMC00-P3P
17
GND
18
FMC05-P3P
19
FMC04-P3P
20
GND
21
FMC03-P3P
22
FMC02-P3P
23
FMC01-P3P
24
GND
25
FMCD0-P3N
26
GND
27
FMCD0-P3N 28 FMC14-P3P
29
FMC13-P3P
30
FMC12-P3P
31 FMC11-P3P 32 FMC10-P3P
33 FMC09-P3P 34 FMC08-P3P
35
GND
36
FMC07-P3P
37 FMC06-P3P 38 FMC05-P3P
39 FMC04-P3P 40 FMC03-P3P
41 FMC02-P3P 42 FMC01-P3P
43
FMC00-P3P
44
FMC-P3V
1T
GND
2T
GND
3T
GND
4T
GND

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
