Toshiba Qosmio F60 Series

Appendices Appendix B Board Layout
B.4 Touch Pad SW board (FLETB*) View
(front)
(back)
Figure B-4 Touch Pad SW board (FLETB*) layout (front/back)
Table B-4 Touch Pad SW board (FLETB*) connector (back)
Number Name
CN3340 Touch DEVICE interface connector
CN9530 System board interface connector
B-6 [CONFIDENTIAL] Qosmio F60 Series Maintenance Manual (960-796)
