Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-13
C.13 CN5300 LCD interface connector (40-pin)
Table C- 13 LCD interface connector (40-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 PNL-P3V
3 PNL-P3V 4
P3V
5
NC
6
TSCL-P3P
7
TSDA-P3P
8
ZLTDA0-PYN
9
ZLTDA0-PYP
10
GND
11 ZLTDA1-PYN 12
ZLTDA1-PYP
13 GND 14
ZLTDA2-PYN
15 ZLTDA2-PYP 16
GND
17
XLTXCA-PYN
18
XLTXCA-PYP
19
GND
20
ZLTDB0-PYN
21
ZLTDB0-PYP
22
GND
23
ZLTDB1-PYN
24
ZLTDB1-PYP
25
GND
26
ZLTDB2-PYN
27
ZLTDB2-PYP
28
GND
29
XLTXCB-PYN
30
XLTXCB-PYP
31
GND
32
GND
33
GND
34
GND
35
BKLPWM-P3P
36
BLEN-E3P
37
NC
38
PVT-EFV
39
PVT-EFV
40
PVT-EFV
1T
GND
2T
GND
3T
GND
4T
GND
5T
GND
6T
GND
7T
GND
8T
GND
9T
GND
10T
GND
11T
GND
