Appendices Appendix B Board Layout
B.6 LED board (FLELE*) View
(front)
(back)
Figure B-6 LED board (FLELE*) layout (front/back)
Table B-6 LED board (FLELE*) connector (back)
Number Name
CN9540 System board interface connector
B-8 [CONFIDENTIAL] Qosmio F60 Series Maintenance Manual (960-796)
