Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-23
Touch Pad SW board (FLETB*)
C.36 CN9530 System interface connector (6-pin)
Table C- 36 System interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1
GND
2
GND
3
IPDDAT-P5P
4
IPDCLK-P5P
5
PDLEON-S3P
6
P5V
1T
GND
2T
GND
C.37 CN3340 Touch DEVICE interface connector (12-pin)
Table C- 37 Touch DEVICE interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1 S3340-3,4 2 NC
3 NC 4
P5V
5 NC 6
S3341-3,4
7 GND 8
GND
9
IPDCLK-P5P
10
IPDDAT-P5P
11
P5V
12
P5V
1T
GND
2T
GND
Touch Pad En-SW board (FLETP*)
C.38 CN3331 System interface connector (2-pin)
Table C- 38 System interface connector (2-pin)
Pin No. Signal Name Pin No. Signal Name
1 S3330-3,4 2 GND
1T GND 2T GND
