4.10 SW board
Removing the SW board
To remove the SW board, follow the steps below and refer to Figure 4-17.
1. Remove the following screw and SW board.
 M2.54B FLAT HEAD screw 1
2. Disconnect the SW board FFC from the connector on the SW board.
M2.5x4B FLAT HEAD
SW board FFC
SW board
Insulator
Figure 4-17 Removing the SW board
4-32 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
