Toshiba Qosmio F60 Series Maintenance Manual

エラー ! スタイルが定義されていません。 エラー ! スタイルが定義されていません。
エラー ! スタイルが定義されていません。 Replacement Procedures エラー !
ス
Installing the optical disk drive
To install the Optical disk drive, follow the steps below and refer to Figure 4-14 to 4-16.
1. When installing a new optical disk drive, set the ODD bezel to the optical disk drive
while securing the latches.
ODD bezel
Optical disk drive
Latch
Figure 4-16 installing the ODD bezel
2. Set the ODD rear bracket to the optical disk drive and secure them with the
following screws.
 M2.02.7C Unique screw 2
3. Set the ODD side bracket to the optical disk drive and secure them with the
following screw.
 M2.03C S-THIN HEAD screw 1
4. Insert the optical disk drive assembly into the slot of the base assembly.
CAUTION: When the optical disk inside the optical disk drive can not be ejected because
of some failure, open the disc tray by inserting a slender object (about 15
mm) such as a straightened paper clip into the eject hole near the eject
button.
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-31

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
