Replacement Procedures
エラー
!
スタイルが定義されて
3. Remove the following screws and ODD rear bracket.
M2.02.7C Unique screw 2
4. Remove the following screw and ODD side bracket.
M2.03C S-THIN HEAD screw 1
ODD rear bracket
M2.0x2.7C Unique
ODD side bracket
M2.0x3C S-THIN HEAD
Figure 4-15 Removing the optical disk drive (2)
4-30 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
