Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-19
C.27 CN4631 FLEJK*(USB/Sound board) interface connector (40-
pin)
Table C- 27 FLEJK*(USB/Sound board) interface connector (40-pin)
Pin No. Signal Name Pin No. Signal Name
1 HEADR-PXP 2 GND
3
HEADL-PXP
4
GND
5
IMICIN-PXP
6
IMICB-P2V
7
DETCTA-P4N
8
EMICB-P2V
9 EMCINR-PXP 10
GND
11
EMCINL-PXP
12
GND
13
NC
14
GND
15
L4630-3
16
L4630-2
17
GND
18
GND
19
NC
20
USB1PS-E5V
21
USB1PS-E5V
22
USB1PS-E5V
1T
GND
2T
GND
C.28 CN3240 FLETB*(Touch Pad SW board) interface connector
(6-pin)
Table C- 28 FLETB*(Touch Pad SW board) interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 TPADLD-S3P
3 IPDCLK-P5P 4
IPDDAT-P5P
5 GND 6
GND
1T
GND
2T
GND
C.29 CN3241 FLETP*(Touch Pad En-SW board) interface
connector (2-pin)
Table C- 29 FLETP*(Touch Pad En-SW board) interface connector (2-pin)
Pin No. Signal Name Pin No. Signal Name
1
TPADON-S3N
2 GND
1T
GND
2T
GND
