Toshiba Qosmio F60 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-18 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)
C.24 IS2621 SIM Card（BCAS, 3D card, other card）interface
connector (8-pin)
Table C-24 SIM Card （ BCAS, 3D card, other card ） interface connector (8-pin)
Pin No. Signal Name Pin No. Signal Name
1
UIMPWR-E3V
2 UIRSTB-E3P
3 UICLKB-E3P 4
5
GND
6 NC
7
UICLKB-E3P
8
9
BCCDET-P3N
10 GND
1T GND 2T GND
C.25 CN9660 Touch Sensor interface connector (10-pin)
Table C-25 SIM Card （ BCAS ） interface connector (8-pin)
Pin No. Signal Name Pin No. Signal Name
1 S3V 2 TOCHEN-S3N
3 GND 4 SSCL-S3P
5
ATTEN-S3P
6
SSDA-S3P
7 TC-S5V 8
TC-S5V
9
GND
10
GND
1T GND 2T GND
C.26 CN3390 FLEPW*(Power SW board) interface connector (14-
pin)
Table C- 26 FLEPW*(Power SW board)interface connector (14-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 PNLOFF-S3N
3 S3V 4 PWRSW-S3N
5 LEDON-P5N 6
P5V
7
P5V
8
DSPRST-S3N
9 10
TSCL-P3P
11 TSDA-P3P 12
LDOCNT-S3P
13 GND 14
GND
1T
GND
2T
GND
