Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-25
Power SW board (FLEPW*)
C.40 CN3410 System interface connector (14-pin)
Table C- 40 System interface connector (14-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 GND
3 4
(LDOCNT-S3P)
5
(FSDA-P3P)
6
(FSCL-P3P)
7
P3V
8
(DSPRST-S3N)
9 P5V 10
P5V
11
LEDON-P5N
12
PWSW-S3N
13 S3V 14
PNLOFF-S3N
1T
GND
2T
GND
C.41 CN3411 2
nd
Display interface connector (10-pin)
Table C- 41 2nd Display interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 P3V 2 P5V
3 P5V 4
(DSPRST-S3N)
5 P3V 6
(FSCL-P3P)
7
(FSDA-P3P)
8
(LDOCNT-S3P)
9 GND 10
GND
1T
GND
2T
GND
