Appendix B Board Layout Appendices
B.7 Power SW board (FLEPW*) View
(front)
(back)
Figure B-7 Power SW board (FLEPW*)layout (front/back)
Table B-7 Power SW board (FLEPW*) connector (back)
Number Name
CN3411 2nd Display interface connector
CN3410 System interface connector (
Qosmio F60 Serie Maintenance Manual (960-796) [CONFIDENTIAL] B-9
