Replacement Procedures
エラー
!
4.27 IR lens
Removing the IR lens
To remove the IR lens, follow the steps below and refer to Figure 4-43.
1. Remove the IR lens form the base assembly.
IR lens
Figure 4-43 Removing the IR lens
Installing the IR lens
To install the IR lens, follow the steps below and refer to Figure 4-43.
1. Set the IR lens to the base assembly.
4-72 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
