LED board (FLELE*)
C.39 CN9540 System interface connector (10-pin)
Table C- 39 System interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 DCINOR-S5N
2
DCINGR-S5N
3 M5V
4 PWLEOR-S5N
5 PWLEGR-S5N
6 BAT1OR-S5N
7 BAT1GR-S5N
8 M5V
9 SATLED-P5N
10 FMLED-P5N
1T GND 2T
GND
