4.12 LED board
Removing the LED board
To remove the LED board, follow the steps below and refer to Figure 4-19.
1. Remove the LED board from the guide of the cover assembly.
2. Disconnect the LED board FFC from the connector on the LED board.
LED board
Hole
Guide
Guide
LED board FFC
Figure 4-19 Removing the LED board
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-35

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
