Toshiba Qosmio F60 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-14 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)
C.14 CN6150 Speaker interface connector (4-pin)
Table C- 14 Speaker interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 SPOTR-PXN 2 SPOTR-PXP
3
SPOTL-PXP
4
SPOTL-PXN
C.15 CN8771 FAN interface connector (4-pin)
Table C- 15 FAN interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 FANG0-P3P
3 GND 4
FPWM0-S3P
1T
GND
2T
GND
C.16 CN8800 DC-IN connector (4-pin)
Table C- 16 DC-IN connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 ADPDC 2 ADPDC
3
GND
4
GND
1T
GND
2T
GND
C.17 CN8810 Battery connector (10-pin)
Table C- 17 Battery connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 Q8811-1pin 2 BTMP1
3 Q8811-4pin 4
M5V
5
PSCL-S5P
6
PSDA-S5P
7
GND
8
DBT1OV-S5N
9
GND
10
GND
