Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-15
C.18 CN9550 WebCam interface connector (6-pin)
Table C- 18 WebCam interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1
GND
2
GND
3
ZUSB11-E3P
4
ZUSB11-E3N
5
P5V
C.19 CN9510 RGB interface connector (12-pin)
Table C- 19 RGB interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2
IDSDA-P3P
3
IDSCL-P3P
4
GND
5
MVSYNC-P3P
6
MHSYNC-P3P
7
GND
8
MBLUE-PXP
9
GND
10
MGREEN-PXP
11
GND
12
MRED-PXP
1T
GND
2T
GND

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
