Tests and Diagnostics
Qosmio F60 Series Maintenance Manual (960-796 [CONFIDENTIAL]) 3-53
The following message appears in the display.
[Touch Pad On/OFF Button test]
Press [Touch Pad On/OFF] Button
Please press a [Touch Pad On/OFF Button].
After checking [Touch Pad On/OFF Button], return to the ONLY ONE TEST
menu automatically.
Subtest 07 Spurs Engine
This subtest checks if Spurs Engine works properly.
OK message appears in the display if the test ends.
NG message appears in the display if a defective is the test.
Press Enter and return to the ONLY ONE TEST menu.
Subtest 08 Fan control
This subtest checks if FAN works properly.
The following message appears in the display in order.
! Start low-speed rotation……….Waits 8 seconds
! Start reading of rotation…………Waits 3 seconds
! Start Hight-speed rotation……..Waits 8 seconds
! Start reading of rotation…………Waits 3 seconds
FAN Low-speed----> Target Low: 3900 Rpm Result Low: XXXX Rpm OK!
FAN High-speed---> Target High: 3800 Rpm Result High: XXXX Rpm OK!
OK message appears in the display if the test ends without a defective.
NG message appears in the display if a defective is found during the test.
Subtest 09 E2PROM (MAC/GUID)
