Toshiba Qosmio F60 Series Maintenance Manual

エラー ! スタイルが定義されていません。 Replacement Procedures エラー ! スタイルが定義されて
い
4-4 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
The main parts in this manual are indicated in the part list by the following names.
Parts List
ITEM No
Manual NAME PART NAME
01A System board PCB ASSY FG6INx
01B Switch board PCB ASSY FG6SWx
01C USB board PCB ASSY FG6USx
01D Serial board PCB ASSY FG6SRx
01E Sound board PCB ASSY FG6SNx
03 Fingerprint sensor board PCB ASSY FGGFSx
04 ODD FPC FREXIBLE PRINTED PCB
07 IC AW80577SH0513M SLB3R
07-A IC LF80537GG0332MN SLAJ5
07-B
CPU
IC AW80576GH0616M SLB46
08 DDR2 800 2GB
08-A
Memory module
DDR2 800 1GB
10 WL-LAN (802.11a/g/n)
10-A WL-LAN (802.11a/g/n)
10-B WL-LAN (802.11b/g)
10-C
Wireless LAN card
WL-LAN (802.11a/g/n)
15 RTC battery BTN N/H BATTERY
19 Optical disk drive DVD-SUPER MULTI DRIVE
45 HDD harness S-ATA HARNESS
46 2.4/5.2GHZ ANTENNA
47
Wireless LAN antenna
2.4/5.2GHZ ANTENNA
50B Brake hinge L BH L ASSY
50C Brake hinge R BH R ASSY
67 Unit dual pad TPAD PLT FP ASSY
S01
M2.03C S-THIN HEAD
T SCREW M2X3CR
S02
M2.02.7 Unique
FHG SCREW M2X2.7
S03
M3.04B FLAT HEAD
T SCREW M3X4CR
S04
M2.03C BIND
G SCREW M2X3CR
S05
M2.04B BIND
G SCREW M2X4BN
S06
M2.54B FLAT HEAD
TG SCREW M2.5X4BN
S07
M2.55B FLAT HEAD
BG SCREW M2.5X5BN
S08
M2.510B FLAT HEAD
TG SCREW M2.5X10BN
S09
M2.516B FLAT HEAD
T SCREW M2.5X16BN
S10
M2.56C Tapping
TG SCREW M2.5X6CR
S11
M2.08C Tapping
TG SCREW M2X8CR
S12
M2.03C Tapping
TG SCREW M2X3CR

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
