Replacement Procedures
エラー
!
3. Open the left and right latches outside and remove the memory module(s).
Latch
Memory module A
Memory module B
Latch
Figure 4-5 Removing the memory module
Installing the memory module
To install the memory module, confirm that the computer is shut down. Then follow the steps
below and refer to Figure 4-4 and 4-5.
CAUTION: Be sure to install a memory module to slot A. The computer does not boot
when a memory module is not installed into the slot A.
Never press hard or bend a memory module.
1. Insert the memory module(s) into the connector on the computer slantwise and press
it to connect firmly.
CAUTION: After installing the memory module, make sure that the memory module is
secured with the left and right latches.
2. Install the memory cover and secure it with the screw.
3. When the power of the computer is turned on, the computer checks automatically the
memory size. Make sure that the new memory is detected correctly.
4. If the memory is not detected, check that it is connected correctly.
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-17
