Toshiba Qosmio F60 Series Maintenance Manual

エラー ! スタイルが定義されていません。 エラー ! スタイルが定義されていません。
エラー ! スタイルが定義されていません。 Replacement Procedures エラー !
ス
3. Remove the HDD from the slot and disconnect it from the connector on the HDD
harness.
HDD
HDD harness
Figure 4-7 Removing the HDD
Installing the HDD
To install the HDD, follow the steps below and refer to Figure 4-6 and 4-7.
1. Connect the HDD to the connector on the HDD harness and lay the HDD down into
the slot.
2. Set the HDD cover and secure it with the following screw.
 M2.54B FLAT HEAD screw 1
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-19

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
