Installing the RTC battery
To install the RTC battery, follow the steps below and refer to Figure 4-24.
1. Stick the RTC battery insulator on the system board in place and set the RTC
battery on the RTC battery insulator.
CAUTION: Do not put the RTC battery harness on the RTC battery.
Do not stick the RTC battery insulator on the ICs of the system board.
Stick the RTC battery insulator as shown in the figure below.
RTC battery insulator
2. Wrap the RTC battery with the RTC battery insulator.
3. Connect the RTC battery harness to the connector CN4632 on the system board.
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-41

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
