QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-45
Installing the wireless LAN card
To install the wireless LAN card, follow the steps below and refer to Figure 4-26.
1. Insert the wireless LAN card into the connector CN2600 on the system board
slantwise.
2. Push down the wireless LAN card and secure it with the following screws.
 M2.04B BIND screw 2
3. Connect the wireless LAN antenna cables to the connectors on the wireless LAN
card.
NOTE: Connect the wireless LAN antenna cables to the connectors (white cable to “A”
or “1” and black cable to “B” or “2”) on the wireless LAN card.

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
